55 Inch LCD Video Wall 700nits High Contrast Slim Bezel 1.7mm Rich Color Original Samsung LG BOE LED Panel
LCD Video Wall Quick Detail:
LED direct-lit backlight with uniform brightness and no boundary shadow.
Resolution: 1920 x 1080
High display resolution, and delicate image with rich color;
High definition, high brightness, high color gamut DID LCD screen with 178° wide angle.
Large display area with light weight Longer display lifespan
Multiple jointing methods, applicable for various scenes.
Stable running and low maintenance cost, support 24 hours continuous wokring.
Metal case enhances the function of anti-radiation, anti-magnetic filed and strong electric field interference.
Working humidity: 10% ~ 90%, able to work under harsh envionment.
LCD Video Wall Feature
1. LCD Industrial HD&High-brightness narrow edge LCD.
2. Narrow Edge Design: Minimum 1.8mm.
3. High Resolution Ratio: 1920*1080
4. High-brightness: 700cd/sqm
5. Super wide visual angle:178(H)/178(V).
LCD Video Wall Specifications
| LCD Technology | Samsung LG BOE |
| Active Screen Diagonal | 55" |
| Pixel Pitch(WxH) | 0.630x0.630mm |
| Active Display Area(WxH) | 1209.6x680.4mm |
| Panel Dimension(WxHxD) | 1211.4x682.2x53.3mm |
| Total Bezel Width | 1.7 mm |
| Aspect Ratio | 16:9 |
| Physical Resolution | 1920x1080 |
| Backlight System | LED |
| Luminance(nits) | 700cd/sqm |
| Contrast | 5000:1 (typ.) |
| Viewing Angle | H 178°|V 178° |
| Display Colors | 8Bit,16.7M |
| Refresh Rate | 60Hz |
| Response Time | <=6ms |
| Life(hrs) | >60,000(hrs) |
| MTBF | > 100,000h |
Noted:
55inch TFT-LCD video wall with semaless bezel and 700cd/m2 high brightness, so the outlooking is like LED wall screen, but resolution is 1920*1080, DP connector is on option, support vertical and horizontal installation.
You can make full screen displaying or random combination displaying, we will supply the full solution including wall-mount bracket/floorstanding cabinet/moving bracket with wheels, HD.MI cables, CAT5 cables/Lan cables, RS232 cables, COM connector and software, so we're one-stop supplier for you.
LCD Video Wall Board Specifications
| Support | PC | Color | 24bit |
| Signal | | Line synchronization range | 30-80KHZ |
| Field synchronization range | 50-75HZ |
| DVI HDMI DP | Color | 24bit |
| Line synchronization range | 30-80KHZ |
| Field synchronization range | 50-75HZ |
| Interface | Input | VGA x 1 | 15pin D-Sub |
| DVI x 1 | DVI-I |
| DP x 1 | Display Port |
| HDMI x 2 | HDMI-19 pin |
| Output | PANEL | LVDS 36Pin/2.0 |
| DP out | DP loop out |
| Power | Input power | DC24V/12V/5V |
| Drive panel | 5V/12V |
| Power mode | Normal working mode, power saving mode |
| Other | OSD | Chinese, English and other languages (other languages can be added as required) |
