55 Inch LCD Video Wall HDMI Rich Color High Brightness Commercial Advertising Screens Monitors 1.7mm Bezel
LCD digital wall technology is a high quality image representative of serial transmission, mainly used in some professional field of television and radio and television, the product supports audio embedded solution, at the same time, supports the highest resolution to 1080p 60Hz, which should be more extensive.
LCD Video Wall Feature
1. LCD Industrial HD&High-brightness narrow edge LCD.
2. Narrow Edge Design: Minimum 1.8mm.
3. High Resolution Ratio: 1920*1080
4. High-brightness: 700cd/sqm
5. Super wide visual angle:178(H)/178(V).
LCD Video Wall Specifications
| LCD Technology | Samsung LG BOE |
| Active Screen Diagonal | 55" |
| Pixel Pitch(WxH) | 0.630x0.630mm |
| Active Display Area(WxH) | 1209.6x680.4mm |
| Panel Dimension(WxHxD) | 1211.4x682.2x53.3mm |
| Total Bezel Width | 1.7 mm |
| Aspect Ratio | 16:9 |
| Physical Resolution | 1920x1080 |
| Backlight System | LED |
| Luminance(nits) | 700cd/sqm |
| Contrast | 5000:1 (typ.) |
| Viewing Angle | H 178°|V 178° |
| Display Colors | 8Bit,16.7M |
| Refresh Rate | 60Hz |
| Response Time | <=6ms |
| Life(hrs) | >60,000(hrs) |
| MTBF | > 100,000h |
Performance Features as follows:
Support a variety of signal ports.
Built-in splicing module, Support splice function
Support Creating one window(PIP) across the screen,roaming service,scaling,PIP
Support matrix joint control.
Dynamic image without motion trail
Splicing image processing RS-232(RJ-45)loop-circuit input/output.
Input by remote control with wire,mobile receiver head.
| Business Organizations | supermarket, large-scale shopping malls, exclusive agency, chain shops, large-scale sales, star-rated hotels, restaurants, travel agencies, pharmacy. |
| Financial Organizations | Banks, negotiable securities, funds, insurance companies, pawnshops; Non-profit Organizations: Telecommunications, post offices, hospital, schools; |
| Public Places | subway, airports, stations, gas stations, toll stations, bookstores, parks, exhibition halls, stadiums, museums, convention centers, ticket agencies, HR market, lottery centers; Real Estate Property: Apartments, villas, offices, commercial buildings, model rooms, property brokers; |
| Entertainments | Movie theaters, fitness halls, country clubs, clubs, massage rooms, bars, cafes, Internet bars, beauty shops, golf course |
