| Main Configuration |
| CPU | Single Version A9 -1G speeds | LED | LG/BOE and others |
| Online Edition 4-cores ARM cortex | Light source | LED backlight |
| Memory | Single Version 256M DDR3 1600M | Conyrast(typ)/(min) | ≥3000:1(typ) |
| Online Edition 1GByte DDR 1600MHz | Reaction time | <8ms |
| Built-in memory | 8GB(optional) | Refresh frequency | 60Hz |
| Operating system | Single Version: No OS | Viewing angle | 89/89/89/89(CR≥10) |
| Online Edition: Android | Lamp tube life | >60000hours |
| Resolution | 1920(RGBW)x 1080[UHD] | Colour saturation | 95% |
| Brightness | ≥300cd/m2 | Number of colors | 16.7M(8-bit 2(LVDS)) |
| Play mode | Support for the cycle,timing,spots and other playback modes | Power | 220V AV 50/60Hz |
| Maximum power | 120w |
| Network support | Ethernet,WiFi,bluetooth4.0,wireless peripherals expansion | Working temperature | 0ºC~50ºC |
| Storage temperature | .-20ºC~60ºC |
| Video playback | Support M,MVB,AVI,MPEG,DAT,MOV, WMV,MKV,RM,RMVB,MPEG,MKV,3GP. | Storage humidity | 10%~60% RH Non-Condensing |
| Working humidity | 20%~80% RH Non-Condensing |
| Pic format | Support BMP,JPEG,PNG,GIF etc. | Display mode | S-IPS,often black display,transmission type |
| USB2.0 interface | 2 USB HOST |
| Ethernet | 1, 10M/100M, adaptive Ethernet | Max use time | 18 hours |
| LVDS output | 1, 50/60Hz LCD screen can be driven directly | Internal horn | 5W*5 |
| Power input | *1 |
| Audio/video output | Left and right channel output(support dual-channels 4R/20W,8R/10W horn) | Power switch | *1 |
| Shell material (face frame/rear shell) | Aluminum alloy/sheet metal |
| Automatic copy function | USB files can be automatically copy into the memory card, the same file overwrite, different file name copies |
| Shell material (face frame/rear shell) | Aluminum alloy/sheet metal |
| RTC time | support | Shell color(face frame/back shell) | Edge silver shell black |
| Timing switch | support |
| System upgrade | support USB/Tcard/network upgrade | Version | Stand-alone/network version |
| Accessory | Controller, Power cord, Instruction of use, Warranty card, Qualified certificate |
